UL Certified! Wired protocol DMX512 + wireless protocol Bluetooth 5.0, Vibrant lighting effects at your fingertips! The series covers dimming, color temperature, RGB, RGBW, RGBWY, and DMX512 programming to meet diverse lighting control needs!Through the Xiaolei Super Intelligent Gateway S80, you can connect to the Apple Home ecosystem and the Matter protocol, enabling interconnection of cross-brand devices.
| Input Voltage | 12-24VDC, Powered by Class 2 Power Supply |
| Wireless Type | Bluetooth 5.0 SlG Mesh |
| Compatible Devices | B5-3A, Bluetooth Driver, Bluetooth Controller |
| Number of Scene | 8 |
| Working Temperature | -25°C~50°C |
| Dimensions (L×W×H) | L120xW75xH30(mm) |
| Package size (L×W×H) | L158xW113xH62(mm) |
| Weight(G.W.) | 225g |
| Control mode | RGBWY |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Control mode | RGBW |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Control mode | CT |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Control mode | DIM |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Control Type | DIM |
| Working Voltage | 3Vdc(AAAx2) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Number of Zones | 4-zone control |
| Matching Touch Panel | EB1/EB6 |
| Compatible Driver | B5-3A |
| Working Temperature | -25°C~50°C |
| Dimensions | 162x42x15mm(LxWxH) |
| Package Size | 166x47x22mm(LxWxH) |
| Weight | 55g±10g |
| Control Type | CT |
| Working Voltage | 3Vdc(AAAx2) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Number of Zones | 4-zone control |
| Matching Touch Panel | EB2/EB6 |
| Compatible Driver | B5-3A |
| Working Temperature | -25°C~50°C |
| Dimensions | 162x42x15mm(LxWxH) |
| Package Size | 166x47x22mm(LxWxH) |
| Weight | 55g±10g |
| Control Type | RGB/RGBW/RGBCW |
| Working Voltage | 3Vdc(AAAx2) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Number of Zones | 4-zone control |
| Matching Touch Panel | EB5/EB6 |
| Compatible Driver | B5-3A |
| Working Temperature | -25°C~50°C |
| Dimensions | 162x42x15mm(LxWxH) |
| Package Size | 166x47x22mm(LxWxH) |
| Weight | 55g±10g |
| Control Type | Scene Control |
| Working Voltage | 3Vdc (1xCR2032 button battery) |
| Wireless Type | Bluetooth 5.2 SlG Mesh |
| Compatible Driver | B5-3A |
| Working Temperature | -15°C~50°C |
| Dimensions | 145x40x12mm(LxWxH) |
| Package Size | 148.5x46x19mm(LxWxH) |
| Weight | 50g±10g |
| Input signal | Bluetooth 5.2 SlG Mesh |
| Input voltage | 12-24V |
| Output voltage | 12-24V |
| Load current | 3Ax5CH Max.15A |
| Load power | 180W@12V 360W@24V |
| Protection | Short circuit, over-temperature, over-current protection, anti-reverse connection protection |
| Operating temperature | -25°C ~ 50°C |
| Dimensions | L91xW37xH21(mm) |
| Package Size | L94xW39xH22(mm) |
| Weight (G.W) | 46g |
| Wireless Protocol Type | Bluetooth 5.0 SIG Mesh,DMX/RDM |
| Output Voltage | 5-24Vdc |
| Input Voltage Range | 5-24Vdc |
| Load Current | 4A×5CH / 5A×4CH Max. 20A |
| Load Power | (0~20W...96W)×5CH Max. 480W |
| Protection | Short circuit, overcurrent, overheat, anti-reverse protection |
| Working Temperature | -20°C ~ 55°C |
| Dimensions | L175×W44×H30(mm) |
| Package Size | L178×W48×H33(mm) |
| Weight (G.W) | 130g |
| Model: | GAM-BLE |
| Wireless Protocol Type: | Bluetooth 5.0 SIG Mesh |
| Output Signal: | 0-10Vx2CH / DMX |
| Working Voltage: | 12 ~ 24Vdc |
| Wireless Spectrum: | 2.4GHZ |
| Working Temperature: | -20°C ~ 55°C |
| Dimensions: | 125×33×20mm(L×W×H) |
| Package Size: | 127×35×22mm(L×W×H) |
| Weight(G. W.): | 60g |
