Innovative Technology Design: One receiver supports six distinct remote controls (patented technology), enabling dimming, color temperature adjustment, and RGB control through a single receiver to meet diverse customer needs. RF remote controls facilitate speed adjustment, brightness control, custom color selection, static color choices, and various dynamic lighting effects.
The Mini Series delivers exceptional value and highly creative design, ensuring distributors experience user-friendly design principles during sales, installers during installation, and end-users during operation.
| Working Frequency: | RF 2.4GHz |
| Power Input: | 5~24Vdc |
| Output: | SPI (Max 10A) |
| Pixel Range: | 8~1020px |
| Working Temp.: | -30℃～55℃ |
| Dimensions: | Remote:L104×W58×H9(mm); Controller:L135×W30×H20(mm) |
| Weight(N.W.): | Remote:42g; Controller:52g |
| Total weight(G.W.): | 145g |
| Compatible Driving IC: | Many kinds can be customized also |
| Working Frequency: | 433.92MHz |
| Power Input: | 12~24Vdc |
| Current Load: | 3A×3CH Max. 9A |
| Output Power: | (0~36W...72W)×3CH |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | Remote:L104×W58×H9(mm); Controller:L135×W30×H20(mm) |
| Weight(N.W.): | Remote:42g; Controller:47g |
| Total Weight(G.W.): | 135g |
| Working Frequency: | 433.92MHz |
| Power Input: | 12~24Vdc |
| Current Load: | 3A×3CH Max. 9A |
| Output Power: | (0~36W...72W)×3CH |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | Remote:L104×W58×H9(mm); Controller:L135×W30×H20(mm) |
| Weight(N.W.): | Remote:42g; Controller:47g |
| Total Weight(G.W.): | 135g |
| Working Frequency: | 433.92MHz |
| Power Input: | 12~24Vdc |
| Current Load: | 3A×3CH Max. 9A |
| Output Power: | (0~36W...72W)×3CH |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | Remote:L104×W58×H9(mm); Controller:L135×W30×H20(mm) |
| Weight(N.W.): | Remote:42g; Controller:47g |
| Total Weight(G.W.): | 135g |
| Working Frequency: | 433.92MHz |
| Power Input: | 12~24Vdc |
| Current Load: | 3Ax4CH Max. 12A |
| Output Power: | (0~36...72W)x4CH |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | Remote:L104×W58×H9(mm); Controller:L125×W33×H20(mm) |
| Weight(N.W.): | Remote:42g; Controller:60g |
| Working Frequency: | 433.92MHz |
| Power Input: | 12~24Vdc |
| Current Load: | 3A×3CH Max. 9A |
| Output Power: | (0~36W...72W)×3CH |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | Remote:L104×W58×H9(mm); Controller:L135×W30×H20(mm) |
| Weight(N.W.): | Remote:42g; Controller:47g |
| Total Weight(G.W.): | 135g |
| Working Frequency: | 433.92MHz |
| Power Input: | 12~24Vdc |
| Current Load: | 3A×3CH Max. 9A |
| Output Power: | (0~36W...72W)×3CH |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | Remote:L104×W58×H9(mm); Controller:L135×W30×H20(mm) |
| Weight(N.W.): | Remote:42g; Controller:47g |
| Total Weight(G.W.): | 135g |
| Working Frequency: | 433.92MHz |
| Power Input: | 12~24Vdc |
| Current Load: | 3A×3CH Max. 9A |
| Output Power: | (0~36W...72W)×3CH |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | Remote:L104×W58×H9(mm); Controller:L135×W30×H20(mm) |
| Weight(N.W.): | Remote:42g; Controller:47g |
| Total Weight(G.W.): | 135g |
| Working Frequency: | 433.92MHz |
| Power Input: | 12~24Vdc |
| Current Load: | 3Ax4CH Max. 12A |
| Output Power: | (0~36...72W)x4CH |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | Remote:L104×W58×H9(mm); Controller:L125×W33×H20(mm) |
| Weight(N.W.): | Remote:42g; Controller:60g |
