The DMX decoder adopts advanced microelectronic control technology to convert standard DMX512/1990 digital signals into CC/CV PWM signals for driving LEDs. Controlled by a DMX512 console, it realizes 0–100% brightness dimming and various dynamic lighting effects. It can control single-color, dual-color, RGB, RGBW, RGBWY and RGBWW LED lights.
| Input signal: | DMX512, RDM |
| Control mode: | DIM/CT/RGB/RGBW/RGBCW |
| Input Voltage: | 12-24Vdc |
| Output Current: | 3A×40CH Max. 120A |
| Output Power: | (0~36W...72W)×40CH Max. 2880W |
| DMX interface: | 3-pin XLR, 5-pin XLR, RJ45, green terminal |
| Number of DMX channels: | CH01, CH02, CH03, CH04, CH05, CH08, CH16, CH24, CH32, CH40 |
| Gray level: | 8bit (256 levels) / 16bit (65536 levels) selectable |
| Dimming curve: | 0.1~9.9, standard, linear, LOG |
| Working Temp.: | -30°C~55°C |
| Dimensions: | L340×W122×H42.5mm |
| Weight (G.W): | 1220g |
| Protection: | anti-reversal protection, shortcircuit, overcurrent, over-temperature protection, auto-recovery. |
| Input signal: | DMX512, RDM |
| Control mode: | DIM/CT/RGB/RGBW |
| Input Voltage: | 12-24Vdc |
| Output Current: | 3A×32CH Max. 96A |
| Output Power: | (0~36W...72W)×32CH Max. 2304W |
| DMX interface: | 3-pin XLR, 5-pin XLR, RJ45, green terminal |
| Gray level: | 8bit (256 levels) / 16bit (65536 levels) selectable |
| Dimming curve: | 0.1~9.9, standard, linear, LOG |
| Working Temp.: | -30°C~55°C |
| Dimensions: | L300×W122×H39mm |
| Weight (G.W): | 1180g |
| Protection: | anti-reversal protection, shortcircuit, overcurrent, over-temperature protection, auto-recovery. |
| Input signal: | DMX512, RDM |
| Control mode: | DIM/CT/RGB |
| Input Voltage: | 12-24Vdc |
| Output Current: | 4A×24CH Max. 96A |
| Output Power: | (0~48W...96W)×24CH Max. 2304W |
| DMX interface: | 3-pin XLR, 5-pin XLR, RJ45, green terminal |
| Gray level: | 8bit (256 levels) / 16bit (65536 levels) selectable |
| Dimming curve: | 0.1~9.9, standard, linear, LOG |
| Working Temp.: | -30°C~55°C |
| Dimensions: | L300×W122×H39mm |
| Weight (G.W): | 1180g |
| Protection: | anti-reversal protection, shortcircuit, overcurrent, over-temperature protection, auto-recovery. |
| Input signal: | DMX512, RDM |
| Control mode: | DIM/CT/RGB/RGBW |
| Input Voltage: | 12-24Vdc |
| Output Current: | 4A×16CH Max. 64A |
| Output Power: | (0-48W...96W)x16CH Max.1536W |
| DMX interface: | 3-pin XLR, RJ45, green terminal |
| Gray level: | 8bit (256 levels) / 16bit (65536 levels) selectable |
| Dimming curve: | 0.1~9.9, standard, linear, LOG |
| Working Temp.: | -30°C~55°C |
| Dimensions: | L180×W122×H39mm |
| Weight (G.W): | 730g |
| Protection: | anti-reversal protection, shortcircuit, overcurrent, over-temperature protection, auto-recovery. |
| Input signal: | DMX512, RDM |
| Control mode: | DIM/CT/RGB |
| Input Voltage: | 12-24Vdc |
| Output Current: | 5A×12CH Max.60A |
| Output Power: | (0-60W...120W)x12CH Max.1140W |
| DMX interface: | 3-pin XLR, RJ45, green terminal |
| Gray level: | 8bit (256 levels) / 16bit (65536 levels) selectable |
| Dimming curve: | 0.1~9.9, standard, linear, LOG |
| Working Temp.: | -30°C~55°C |
| Dimensions: | L180×W122×H39mm |
| Weight (G.W): | 730g |
| Protection: | anti-reversal protection, shortcircuit, overcurrent, over-temperature protection, auto-recovery. |
| Input signal: | DMX512, RDM |
| Control mode: | DIM/CT/RGB/RGBW/RGBCW |
| Input Voltage: | 12-48V⎓ |
| Output Current: | 6Ax5CH Max.30A |
| Output Power: | (0-72W...288W)x5CH Max.1440W |
| DMX interface: | 3-pin XLR, RJ45, green terminal |
| Gray level: | 8bit (256 levels) / 16bit (65536 levels) selectable |
| Dimming curve: | 0.1~9.9, standard, linear, LOG |
| Working Temp.: | -30°C~55°C |
| Dimensions: | L169×W80×H39mm |
| Weight (G.W): | 550g |
| Protection: | anti-reversal protection, shortcircuit, overcurrent, over-temperature protection, auto-recovery. |
| Input signal: | DMX512, RDM |
| Control mode: | DIM/CT/RGB/RGBW |
| Input Voltage: | 12-48V⎓ |
| Output Current: | 8Ax4CH Max.32A |
| Output Power: | (0~96W...384W)×4CH Max. 1536W |
| DMX interface: | 3-pin XLR, RJ45, green terminal |
| Gray level: | 8bit (256 levels) / 16bit (65536 levels) selectable |
| Dimming curve: | 0.1~9.9, standard, linear, LOG |
| Working Temp.: | -30°C~55°C |
| Dimensions: | L169×W80×H39mm |
| Weight (G.W): | 550g |
| Protection: | anti-reversal protection, shortcircuit, overcurrent, over-temperature protection, auto-recovery. |
| Input signal: | DMX512, RDM |
| Control mode: | DIM/CT/RGB |
| Input Voltage: | 12-48V⎓ |
| Output Current: | 10Ax3CH Max.30A |
| Output Power: | (0~120W...480W)x3CH Max.1440W |
| DMX interface: | 3-pin XLR, RJ45, green terminal |
| Gray level: | 8bit (256 levels) / 16bit (65536 levels) selectable |
| Dimming curve: | 0.1~9.9, standard, linear, LOG |
| Working Temp.: | -30°C~55°C |
| Dimensions: | L169×W80×H39mm |
| Weight (G.W): | 550g |
| Protection: | anti-reversal protection, shortcircuit, overcurrent, over-temperature protection, auto-recovery. |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12-48V⎓ |
| Output Current: | 8A×3CH 6A×4CH 5A×5CH Max.25A |
| Output Voltage: | 5×(12-48V⎓) |
| Output Power: | 300W@12V 600W@24V 900W@36V 1200W@48V |
| Dimming Range: | 0-100% |
| Working Temp.: | -25°C~55°C |
| Dimensions: | L175×W55×H30mm |
| Package Size: | L188×W61×H40mm |
| Weight (G.W): | 370±5g |
| Protection: | Short-circuit, over-temperature, over-current, and reverse polarity protection, with automatic recovery. |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12-48V⎓ |
| Output Current: | 8A×3CH 6A×4CH 5A×5CH Max.25A |
| Output Voltage: | 5×(12-48V⎓) |
| Output Power: | 300W@12V 600W@24V 900W@36V 1200W@48V |
| Dimming Range: | 0-100% |
| Working Temp.: | -25°C~55°C |
| Dimensions: | L175×W55×H30mm |
| Package Size: | L188×W61×H40mm |
| Weight (G.W): | 370±5g |
| Protection: | Short-circuit, over-temperature, over-current, and reverse polarity protection, with automatic recovery. |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12-48V⎓ |
| Output Current: | 8A×3CH 6A×4CH Max.24A |
| Output Voltage: | 4×(12-48V⎓) |
| Output Power: | 288W@12V 576W@24V 864W@36V 1152W@48V |
| Dimming Range: | 0-100% |
| Working Temp. | -25°C~55°C |
| Dimensions: | L175×W55×H30mm |
| Package Size: | L188×W61×H40mm |
| Weight (G.W): | 365±5g |
| Protection: | Short-circuit, over-temperature, over-current, and reverse polarity protection, with automatic recovery. |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12-48V⎓ |
| Output Current: | 8A×3CH 6A×4CH Max.24A |
| Output Voltage: | 4×(12-48V⎓) |
| Output Power: | 288W@12V 576W@24V 864W@36V 1152W@48V |
| Dimming Range: | 0-100% |
| Working Temp.: | -25°C~55°C |
| Dimensions: | L175×W55×H30mm |
| Package Size: | L188×W61×H40mm |
| Weight (G.W): | 365±5g |
| Protection: | Short-circuit, over-temperature, over-current, and reverse polarity protection, with automatic recovery. |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12-48V |
| Output Current: | 8Ax3CH 6Ax4CH 5Ax5CH Max.25A |
| Output Voltage: | 5×(12-48V) |
| Output Power: | 300W@12V 600W@24V 900W@36V 1200W@48V |
| Dimming Range: | 0-100% |
| Working Temp.: | -25℃-55℃ |
| Dimensions: | L175xW55xH30mm |
| Package Size: | L188xW61xH40mm |
| Weight (G.W): | 370g |
| Protection: | short circuit, over temperature, over current protection, anti-reverse protection, self-recovery |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12-48V |
| Output Current: | 8Ax3CH 6Ax4CH 5Ax5CH Max.25A |
| Output Voltage: | 5×(12-48V) |
| Output Power: | 300W@12V 600W@24V 900W@36V 1200W@48V |
| Dimming Range: | 0-100% |
| Working Temp.: | -25℃-55℃ |
| Dimensions: | L175xW55xH30mm |
| Package Size: | L188xW61xH40mm |
| Weight (G.W): | 370g |
| Protection: | short circuit, over temperature, over current protection, anti-reverse protection, self-recovery |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12-48V |
| Output Current: | 8A×3CH 6A×4CH Max.24A |
| Output Voltage: | 4×(12-48V) |
| Output Power: | 288W@12V 576W@24V 864W@36V 1152W@48V |
| Dimming Range: | 0-100% |
| Working Temp.: | -25℃-55℃ |
| Dimensions(L×W×H): | L175×W46×H30(mm) |
| Package Size(L×W×H): | L187×W52×H36(mm) |
| Weight (G.W): | 325g±5g |
| Protection: | Short circuit, over temperature, over current protection, auto recovery. |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12-48V |
| Output Current: | 8A×3CH 6A×4CH Max.24A |
| Output Voltage: | 4×(12-48V) |
| Output Power: | 288W@12V 576W@24V 864W@36V 1152W@48V |
| Dimming Range: | 0-100% |
| Working Temp.: | -25℃-55℃ |
| Dimensions: | L175×W46×H30(mm) |
| Package Size: | L187×W52×H36(mm) |
| Weight (G.W): | 325g±5g |
| Protection: | Short circuit, over temperature, over current protection, auto recovery. |
| Input signal: | DMX512, RDM |
| Input Voltage: | 100-240V~ |
| Input current: | Max. 6.4A |
| Output Voltage: | 4x(100-240)V⎓ |
| Output Current: | 4CHx1.6A Max.6.4A |
| Output Power: | 4CHx(0-160...384)W Max. 1536W |
| Working Temp. | -25°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight (G.W) | 670g |
| Waterproof rating: | IP67 |
| Protect: | Short-circuit, over-temperature, and over-current protection |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12-48V⎓ |
| Input current: | Max. 20.5A |
| Output Voltage: | 4x(12-48)V⎓ |
| Output Current: | 2x(4CHx2.5A) Max.20A |
| Output Power: | 4CHx(0-60...240)W Max. 960W |
| Working Temp. | -20°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight (G.W) | 670g |
| Waterproof rating: | IP67 |
| Protect: | Short-circuit, over-temperature and over-current protection with automatid reset capability |
| Input signal: | DMX512/RDM |
| Input Voltage: | 12-24V |
| Output Current: | Max. 5A/CH Max. 20A(4CH) |
| Output Power: | (0-60...120)W/CH Max. 480W(4CH) |
| Dimming Range: | 0-100% |
| Working Temp.: | -20°C~50°C |
| Dimensions(L×W×H): | L164×W70×H36mm |
| Package Size(L×W×H): | L193×W127×H41mm |
| Weight (G.W): | 690g |
| Protection: | Short circuit, over temperature, over current protection, auto recovery. |
| Input signal: | DMX512/RDM |
| Input Voltage: | 100-240V~ |
| Output Current: | Max. 1.2A/CH Max. 3.6A(3CH) |
| Output Power: | (83-288)W/CH Max. 864W(3CH) |
| Dimming Range: | 0-100% |
| Working Temp.: | -20°C~50°C |
| Dimensions(L×W×H): | L164×W70×H36mm |
| Package Size(L×W×H): | L193×W127×H41mm |
| Weight (G.W): | 670g |
| Protection: | Short circuit, over temperature, over current protection, auto recovery. |
| Input signal: | DMX512, RDM |
| Input Voltage: | 5-24V |
| Output Type: | Constant Voltage |
| Output Current: | 5Ax3CH 4Ax4CH Max.16A |
| Output Voltage: | 4x(5-24V) |
| Output Power: | 192W@12V 384W@24V |
| Installation method: | Installation of guide rails or screws |
| Install the guide rail: | TS-35/7.5 or TS-35/15 |
| Dimming Range: | 0-100% |
| Working Temp.: | -25℃~50℃ |
| Dimensions: | L112xW35xH67mm |
| Package Size: | L114xW37xH70mm |
| Weight (G.W): | 135g ± 5g |
| Protection: | Short circuit, over temperature, over current protection, can be self restored |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Current load: | 3Ax40CH Max.120A |
| Output power: | (0~36W..72W)x40CH Max.2880W |
| DMX interfaces: | 3-pin XLR, 5-pin XLR,RJ45,Green terminal |
| Number of DMX channels: | CH01,CH02,CH03,CH04,CH05,CH08,CH16,CH24,CH32,CH40 |
| Dimming curves: | 0.1~9.9,standard, linear,LOG |
| Grey level: | 8bit(256levels)/16bit(65536levels) |
| Photoelectric Isolation: | Yes |
| Protection: | Short circuit / Overheat /Over current protection,recover automatically |
| Working temperature: | -30℃～65℃ |
| Dimensions: | L340xW122xH42.5mm |
| Package size: | L350xW149xH47.5mm |
| Weight (G.W): | 1220g |
| Input signal | DMX512/RDM |
| Input voltage | 12-24Vdc |
| Max load current | 3A×32CH Max. 96A |
| Max output power | (0~36W...72W) x32CH Max.2304W |
| DMX512 socket | XLR-3, XLR-5, RJ45, Green terminal |
| Control mode | DIM/CT/RGB/RGBW |
| DIM Curve | 0.1～9.9 |
| Gray scale level | 8bit(256 levels)/16bit(65536 levels) |
| Photoelectric Isolation | Yes |
| Working temperature | -30℃～65℃ |
| Dimension | L300×W122×H39(mm) |
| Package Size | L309×W127×H41(mm) |
| Weight (G.W) | 1180g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 3A×32CH Max 96A |
| Max output power: | (0~36W...72W) × 32CH Max. 2304W |
| DMX512 socket: | 3-pin XLR, 5-pin XLR, RJ45, Green terminal |
| Control mode: | DIM/CT/RGB/RGBW |
| Gray scale level: | 8bit (256 levels) / 16bit (65536 levels) |
| Photoelectric Isolation: | Yes |
| Working temperature: | -30℃～65℃ |
| Dimension: | L300×W122×H39mm |
| Package Size: | L313×W127×H41mm |
| Weight (G.W): | 1180g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 3A×24CH Max. 72A |
| Max output power: | (0~36W...72W) x24CH Max.1728W |
| DMX512 socket: | XLR-3, XLR-5, RJ45, Green terminal |
| Control mode: | DIM/CT/RGB |
| DIM Curve: | 0.1～9.9 |
| Gray scale level: | 8bit(256 levels)/16bit(65536 levels) |
| Photoelectric Isolation: | Yes |
| Working temperature: | -30℃～65℃ |
| Dimension: | L300×W122×H39(mm) |
| Package Size: | L309×W127×H41(mm) |
| Weight (G.W): | 1180g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 3A×24CH Max 72A |
| Max output power: | (0~36W...72W) × 24CH Max. 1728W |
| DMX512 socket: | 3-pin XLR, 5-pin XLR, RJ45, Green terminal |
| Control mode: | DIM/CT/RGB |
| Gray scale level: | 8bit (256 levels) / 16bit (65536 levels) |
| Photoelectric Isolation: | Yes |
| Working temperature: | -30℃～65℃ |
| Dimension: | L300×W122×H39mm |
| Package Size: | L313×W127×H41mm |
| Weight (G.W): | 1180g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 3A × 16CH Max 48A |
| Max output power: | (0~36W...72W) × 16CH Max. 1152W |
| DMX512 socket: | 5-pin XLR, RJ45, Green terminal |
| Control mode: | DIM/CT/RGB/RGBW |
| DIM Curve: | 0.1～9.9 |
| Gray scale level: | 8bit(256 levels)/16bit(65536 levels) |
| Photoelectric Isolation: | Yes |
| Working temperature: | -30℃～65℃ |
| Dimension: | L180×W122×H39mm |
| Package Size: | L193×W127×H41mm |
| Weight (G.W): | 730g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 3A×16CH Max 48A |
| Max output power: | (0~36W...72W) × 16CH Max. 1152W |
| DMX512 socket: | 3-pin XLR, RJ45, Green terminal |
| Control mode: | DIM/CT/RGB/RGBW |
| Gray scale level: | 8bit (256 levels) / 16bit (65536 levels) |
| Photoelectric Isolation: | Yes |
| Working temperature: | -30℃～65℃ |
| Dimension: | L180×W122×H39mm |
| Package Size: | L193×W127×H41mm |
| Weight (G.W): | 730g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 4A×12CH Max 48A |
| Max output power: | (0~48W...96W) × 12CH Max. 1152W |
| DMX512 socket: | 3-pin XLR, RJ45, Green terminal |
| Control mode: | DIM/CT/RGB |
| Gray scale level: | 8bit (256 levels) / 16bit (65536 levels) |
| Photoelectric Isolation: | Yes |
| Working temperature: | -30℃～65℃ |
| Dimension: | L180×W122×H39mm |
| Package Size: | L193×W127×H41mm |
| Weight (G.W): | 753.6g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 4A×12CH Max. 48A |
| Max output power: | (0~48W...96W) x12CH Max.1152W |
| DMX512 socket: | XLR-5, RJ45, Green terminal |
| Control mode: | DIM/CT/RGB |
| DIM Curve: | 0.1～9.9 |
| Gray scale level: | 8bit(256 levels)/16bit(65536 levels) |
| Photoelectric Isolation: | Yes |
| Working temperature: | -30℃～65℃ |
| Dimension: | L180×W122×H39(mm) |
| Package Size: | L193×W127×H41(mm) |
| Weight (G.W): | 762.5g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 6A×5CH Max. 30A |
| Max output power: | (0~72W...144W) x5CH Max.720W |
| DMX512 socket: | XLR-3, RJ45, Green terminal |
| Control mode: | DIM/CT/RGB/RGBW/RGBWY |
| DIM Curve: | 0.1～9.9 |
| Gray scale level: | 8bit(256 levels)/16bit(65536 levels) |
| Photoelectric Isolation: | Yes |
| Working temperature: | -30℃～65℃ |
| Dimension: | L169×W80×H39(mm) |
| Package Size: | L182×W91×H41(mm) |
| Weight (G.W): | 500g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 6Ax5CH Max. 30A |
| Max output power: | (0~72W...144W) x5CH Max. 720W |
| DMX512 socket: | 3-pin XLR, RJ45, green terminal |
| Gray scale level: | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature: | -30℃～65℃ |
| Dimension: | L169×W80×H39mm |
| Package Size: | L182×W91×H41mm |
| Weight (G.W): | 550g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 5Ax5CH Max. 25A |
| Max output power: | (0~60W...120W) x5CH Max. 600W |
| DMX512 socket: | 3-pin XLR, RJ45 |
| Control mode: | DIM/CT/RGB/RGBW/RGBWY |
| Gray scale level: | 8bit (256 levels) / 16bit (65536 levels) |
| Photoelectric Isolation: | Yes |
| Working temperature: | -30℃～65℃ |
| Dimension: | L122×W110×H37(mm) |
| Package Size: | L127×W123×H41mm |
| Weight (G.W): | 510.7g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 6Ax4CH Max. 24A |
| Max output power: | (0~72W...144W) x4CH Max. 576W |
| DMX512 socket: | 3-pin XLR, RJ45 |
| Gray scale level: | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature: | -30℃～65℃ |
| Dimension: | L122×W110×H37(mm) |
| Package Size: | L127×W123×H41mm |
| Weight (G.W): | 550g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 6Ax4CH Max. 24A |
| Max output power: | (0~72W...144W) x4CH Max. 576W |
| DMX512 socket: | 3-pin XLR, RJ45 |
| Working temperature: | -30℃～65℃ |
| Dimension: | L122×W110×H37(mm) |
| Package Size: | L127×W123×H41mm |
| Weight (G.W): | 550g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 8Ax3CH Max. 24A |
| Max output power: | (0~96W...192W) x3CH Max. 576W |
| DMX512 socket: | 3-pin XLR, RJ45 |
| Gray scale level: | 8bit (256 levels) / 16bit (65536 levels) |
| Working temperature: | -30℃～65℃ |
| Dimension: | L122×W110×H37(mm) |
| Package Size: | L127×W123×H41mm |
| Weight (G.W): | 550g |
| Input signal: | DMX512/RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 8A x 3CH Max. 24A |
| Max output power: | (0~96W...192W) x3CH Max. 576W |
| DMX512 socket: | 3-pin XLR, RJ45 |
| Working temperature: | -30℃～65℃ |
| Dimension: | L122×W110×H37(mm) |
| Package Size: | L127×W123×H41mm |
| Weight (G.W): | 550g |
| Input signal: | DMX512, RDM |
| Input Voltage: | 5-24V |
| Output Current: | 2A×5CH Max. 10A |
| Output Voltage: | 5×(5-24V) |
| Output Power: | 50W@5V 120W@12V 240W@24V |
| Dimming Range: | 0-100% |
| Working Temp.: | -25℃-50℃ |
| Dimensions: | L76×W25.5×H11mm |
| Weight (G.W): | 11g±3g |
| Protection: | Short circuit, over-temperature, anti-reverse protection and self recovery. |
| Input signal: | DMX512, RDM |
| Input Voltage: | 5~24Vdc |
| Current Load: | 6A×3CH Max. 18A |
| Output Power: | 90W@5V 216W@12V 432W@24V |
| DMX512 Socket: | Green Teminal |
| Protection: | Short circuit / Over current protection |
| Working Temp.: | -30℃~65℃ |
| Dimensions: | L175×W42×H33mm |
| Package Size: | L183×W48×H41mm |
| Weight (G.W): | 310g |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12~24Vdc |
| Current Load: | 5A×4CH Max. 20A |
| Output Power: | (0~60W...120W)×4CH Max.480W |
| DMX512 Socket: | Green Teminal |
| Protection: | Short circuit / Over load recover automatically |
| Working Temp.: | -30℃~65℃ |
| Dimensions: | L175×W42×H33mm |
| Package Size: | L183×W48×H41mm |
| Weight (G.W): | 310g |
| Input signal: | DMX512, RDM |
| Input Voltage: | 5~24Vdc |
| Current Load: | 4A×3CH Max.12A |
| Output Power: | 60W@5V 144W@12V 288W@24V |
| DMX512 Socket: | XLR-3, Green Terminal |
| Dimming Range: | 0-100% |
| Working Temp.: | -25℃~55℃ |
| Dimensions: | L125×W64×H40mm |
| Package Size: | L135×W70×H50(mm) |
| Weight (G.W): | 305g |
| Input signal: | DMX512, RDM |
| Input Voltage: | 5~24Vdc |
| Current Load: | 6A×4CH 8A×3CH Max.24A |
| Output Power: | 120W@5V 288W@12V 576W@24V |
| DMX512 Socket: | 3-pin XLR, RJ45, Green Terminal |
| Dimming Range: | 0-100% |
| Protection: | Short circuit / Over current |
| Working Temp.: | -25℃~55℃ |
| Dimensions: | L156×W78×H40(mm) |
| Package Size: | L180×W82×H48(mm) |
| Weight (G.W): | 445g |
| Input signal: | DMX512, RDM |
| Input voltage: | 12-24Vdc |
| Max load current: | 12A×1CH + 0-10V×1CH |
| Max output power: | 0~144W...288W |
| Dimming range: | 0～100% |
| Working temperature: | -30℃～55℃ |
| Dimension: | L175×W44×H30(mm) |
| Input signal: | DMX512(8bit/16bit) |
| Input voltage: | 5-24Vdc |
| Max load current: | 5A ×4CH Max 20A |
| Max output power: | (0...25~120W)×4CH Max.480W |
| Dimming range: | 0～100% |
| Working temperature: | -30℃～55℃ |
| Dimension: | L175×W44×H30(mm) |
![[field:title/]](/images/pdf.jpg "12-24VDC 40CHx3A CV DMX512/RDM Decoder D40 Manual"){kind=small}
