Super Smart Gateway, supporting the Matter wireless transmission protocol for smart homes and Apple's Home ecosystem. Dedicated to breaking down ecosystem barriers and achieving more inclusive whole-home connectivity.
| Wireless network: | Bluetooth 5.0 SIG Mesh , Wi-Fi 2.4G＋5G |
| Power Supply: | 100-240V~，50/60Hz，μ |
| Display: | 4-inch full lamination, 480×480 resolution |
| Touchpad: | Capacitive multi-touch screen, anti-fingerprint coating |
| Materials: | PC+ V0 fireproof grade |
| Channel of Load: | 2CH |
| Inrush Current in Loads: | Max. 65A@2ms |
| Working Temp.: | -15°C~50°C, Humidity≤85%RH |
| Dimensions: | L86×W86×H41(mm) |
| Colors: | Grey, Gold, White |
| Wireless type: | Bluetooth 5.0 SIG Mesh |
| Wired network: | Ethernet |
| Control type: | LED driver, switch panel, curtain motor, local scene |
| Supported platforms: | Apple Home、Amazon Alexa、Google Home、SmartThings, etc. |
| Input power: | 5V⎓1A（USB-A） |
| Power interface: | Type-C |
| Working Temp.: | -20°C~55°C |
| Dimensions: | L90×W90×H55(mm) |
| Weight(G.W.): | 380g |
![[field:title/]](/images/pdf.jpg "Super Panel 4S SP-GW-4S Manual"){kind=small}
