0-10V, 1-10V, 10V PWM dimming buttons and dimming modules;
Dimming range: 0–100%, with dimming starting from 0.1%, ideal for indoor LED lighting applications.
| Wireless Protocol: | Matter over Thread, BLE(Network Configuration & Debugging), NFC(DMX Parameter Setting) |
| Control Type: | CT |
| Rated Parameters: | 100-240Vac, 50/60Hz |
| Output Signal: | 0-10V |
| Compatible Driver: | 0-10V CCT |
| Compatible APP: | NFC Lighting, Apple Home, Smarthings, Google Home, Amazon, Aqara, Tuya |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L86×W86×H52(mm) |
| Package Size: | L102×W102×H73(mm) |
| Weight(G.W.): | 130g |
| Wireless Protocol: | Matter over Thread, BLE(Network Configuration & Debugging), NFC(DMX Parameter Setting) |
| Control Type: | DIM |
| Rated Parameters: | 100-240Vac, 50/60Hz |
| Output Signal: | 0-10V |
| Compatible Driver: | 0-10V DIM |
| Compatible APP: | NFC Lighting, Apple Home, Smarthings, Google Home, Amazon, Aqara, Tuya |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L86×W86×H52(mm) |
| Package Size: | L102×W102×H73(mm) |
| Weight(G.W.): | 130g |
| Output Signal: | 0-10V |
| Rated Parameters: | 100-240V~，50/60Hz |
| Control Type: | DIM, CT |
| Wireless Protocol: | Bluetooth 5.0 SIG Mesh |
| Compatible remote: | B1、B2、B8、RC4-BLE |
| Compatible Driver: | 0-10V dimming, color temperature drive |
| Compatible APP: | L-Home、 NFC Lighting |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L86xW86xH52(mm) |
| Package Size: | L102xW102xH73(mm) |
| Weight(G.W.): | 130g |
| Peak current: | 70mA@16V |
| Static current: | 5mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | DALI-2 |
| Output signal: | 0/1-10V×2CH，Max.15mA |
| Load parameters: | Resistive load: 800W@230Vac，400W@110Vac，200W@48Vdc Capacitive load: 300W@230Vac，150W@110Vac，100W@48Vdc |
| Switch maximum voltage: | Max.250Vac，Max.48Vdc |
| Relay surge current: | 70A@10ms |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L45xW45.5xH20.5(mm) |
| Weight(G.W.): | 30g |
| Peak current: | 70mA@16V |
| Static current: | 5mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | DALI-2 |
| Output signal: | 0/1-10V×2CH，Max.15mA |
| Load parameters: | Resistive load: 800W@230Vac，400W@110Vac，200W@48Vdc Capacitive load: 300W@230Vac，150W@110Vac，100W@48Vdc |
| Switch maximum voltage: | Max.250Vac，Max.48Vdc |
| Relay surge current: | 70A@10ms |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L45xW45.5xH20.5(mm) |
| Weight(G.W.): | 30g |
| Model: | CG-DAM-PRO |
| Wireless Protocol: | Bluetooth 5.0 SIG Mesh |
| Output Signal: | DMX / DALI / 0-10V |
| Input Voltage: | 100-240Vac |
| DALI Output: | 12Vdc (Max.90mA) |
| Working Temp.: | -20°C~55°C |
| Dimensions: | L84×W35×H23(mm) |
| Package Size: | L100×W70×H42(mm) |
| Weight(G.W.): | 30g |
| Input voltage: | 100-240V~,50/60Hz |
| Input signal: | PUSH DIM |
| Output signal: | 0-10V, MAX.15mA |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L45xW45.5xH20.5(mm) |
| Weight(G.W.): | 30g |
| Wireless Protocol: | Bluetooth5.0 SIG Mesh |
| Power voltage: | 120-277Vac,50/60Hz |
| Load power: | 400VA(Capacitive load),800W(Resistive load) |
| Microwave frequency: | 10.525GHz |
| Emission frequency: | 2dB |
| Stand-by power consumption: | ≤1W |
| Ceiling height: | ≤3.3m |
| Detection range: | ≤6m |
| IP rating: | IP20 |
| Dimensions: | 83*83*72mm(LxWxH) |
| Power voltage: | 120-277Vac,50/60Hz |
| Load power: | 400VA(Capacitive load),800W(Resistive load) |
| Microwave frequency: | 5.8GHz±75MHz |
| Emission frequency: | ≤0.5mW |
| Stand-by power consumption: | ≤0.5W |
| Ceiling height: | ≤6m |
| Detection range: | ≤10m |
| IP rating: | IP20 |
| Dimensions: | 95*45*26.5mm(LxWxH) |
| Input: | 100-240Vac, 50-60Hz |
| Communication Mode: | RF 2.4GHz |
| Output: | 0-10V×2CH, 15mA×2CH |
| Anti Surge: | ≤50A/0.1S |
| Working Temp.: | -10°C~55°C |
| Dimensions: | L86×W86×H50(mm) |
| Package Size: | L105×W105×H63(mm) |
| Weight(G.W.): | 220g |
| Dimming interface: | DMX/RDM,DALI,Push Dim |
| Output signal: | 0-10V×4CH |
| Output signal logic: | High potential |
| Input voltage: | 100-240Vac/277Vac (277 Vac for North America only) |
| Dimming range: | 0～100% |
| Dimensions: | L175×W44×H30(mm) |
| Pacakge size: | L178×W48×H33(mm) |
| Weight(G.W.): | 110g±10g |
| Control Type: | Dim / CT |
| Wireless Protocol: | RF 2.4GHz |
| Input Voltage: | 100-240Vac |
| Output Signal: | 0-10V×2 |
| Output Current: | 15mA×2 Channel |
| Power Consumption: | 1W |
| Dimensions: | L86×W86×H36mm(mm) |
| Package Size: | L113×W12×H50(mm) |
| Weight(G.W.): | 225g |
| Model: | GAM-BLE |
| Wireless Protocol: | Bluetooth 5.0 SIG Mesh |
| Output Signal: | 0-10Vx2CH / DMX |
| Working Voltage: | 12 ~ 24Vdc |
| Wireless Spectrum: | 2.4GHz |
| Working Temp.: | -20°C ~ 55°C |
| Dimensions: | L125×W33×H20(mm) |
| Package Size: | L127×W35×H22(mm) |
| Weight(G. W.): | 60g |
| Input Voltage: | 100～240Vac 50-60Hz |
| Output: | 0~10V Max. 50mA |
| Switching Power: | 90~250Vac, 5A |
| Wireless Protocol: | RF 2.4GHz |
| Working Temp.: | -10℃～55℃ |
| Dimensions: | L86×W86×H50(mm) |
| Package Size: | L106×W106×H60(mm) |
| Weight(G.W.): | 220g |
| Control Mode: | RF wireless control with 0-10V/10V PWM output control |
| Input Voltage: | 100-240Vac |
| Output Signal: | 0-10V |
| Wireless Protocol: | RF 2.4GHz |
| Working Temp.: | -20℃~55℃ |
| Dimensions: | L86×W86×H36(mm) |
| Package Size: | L113×W112×H50(mm) |
| Weight(G.W.): | 225g |
| Input Voltage: | 100～240Vac 50-60Hz |
| Output: | 0~10V Max. 15mA |
| Inrush current: | ≤50A / 0.1S |
| Switching Power: | 90~250Vac, 5A |
| Working Temp.: | -10℃~55℃ |
| Dimensions: | L86×W86×H50(mm) |
| Package Size: | L106×W106×H60(mm) |
| Weight(G.W.): | 220g |
| Output Signal: | 1-10V, Max. 50mA |
| Switching Voltage: | Max. 250Vac |
| Switching Current: | Max. 5A |
| Anti Surge: | ≤50A / 0.1S |
| Working Temp.: | -10℃～55℃ |
| Dimensions: | L86×W86×H50(mm) |
| Package Size: | L106×W106×H60(mm) |
| Weight(G.W.): | 220g |
| Input Voltage: | 5~24Vdc |
| Output: | 10VPWM |
| Wireless Signal: | RF 2.4GHz |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | L55×W55×H21(mm) |
| Package Size: | L65×W65×H26(mm) |
| Weight(G.W.): | 70g |
