CC Dimmable Driver(UL Certified) - North America UL

Product features:

1. T-PWM^® super-deep dimming technology, dimming starting from 0.1%. 2. Flicker-free dimming across the entire range, meeting the High-Frequency Exemption Level. 3. NFC Programmable Technology: Allows configuration of parameters (e.g., output current, dimming curve) and driver data exchange via a mobile app. 4. EU ErP Compliance: No-load and networked standby power consumption is <0.5W· 0V No-Load Output prevents damage to LEDs caused by poor contact. 5. novative Thermal Management, intelligently extending driver service life. 6. Protection against Over-Temperature, Over-Load, and Short-Circuit, with Auto-Recovery.

CC Dimmable Driver

SE-20-100-700-W2D

Rubycon capacitor
Dimming Interface:	DALI-2 DT6/DT8
DC Voltage Range:	120-300Vdc
AC Voltage Range:	100-240Vac
Input Voltage:	115Vac/230Vac
Power Factor:	PF>0.95/115Vac , PF>0.90/230Vac, at full load
Efficiency:	86%
Fluctuation Level:	No visible flicker/High frequency exemption level
Output Voltage:	9-42Vdc
Output Current:	100-700mA
Output Power:	0.9W~20.4W
Dimming Range:	0~100%, down to 0.01%
Certification:	CCC,FCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,PSE,EL,ROHS
Warranty:	5 years（Rubycon capacitor）

Download Manual

SE-30-200-800-W1D

Rubycon capacitor
Dimming Interface:	DALI-2 DT6
DC Voltage Range:	120-250Vdc
AC Voltage Range:	100-240Vac
Input Voltage:	115Vac/230Vac
Power Factor:	PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
Efficiency:	87%
Fluctuation Level:	No visible flicker/High frequency exemption level
Output Voltage:	9-42Vdc
Output Current:	200-800mA
Output Power:	1.8W-30W
Dimming Range:	0~100%, down to 0.01%
Certification:	CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,FCC,PSE,EL,ROHS
Warranty:	5 years（Rubycon capacitor）

Download Manual

SE-40-300-1050-W1D

Rubycon capacitor
Dimming Interface:	DALI-2 DT6
DC Voltage Range:	120-250Vdc
AC Voltage Range:	100-240Vac
Input Voltage:	115Vac/230Vac
Power Factor:	PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
Efficiency:	88%
Fluctuation Level:	No visible flicker/High frequency exemption level
Output Voltage:	9-42Vdc
Output Current:	300-1050mA
Output Power:	2.7W-40W
Dimming Range:	0~100%, down to 0.01%
Certification:	CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,FCC,PSE,EL,ROHS
Warranty:	5 years（Rubycon capacitor）

Download Manual

SE-30-200-800-W2D

Rubycon capacitor
Dimming Interface:	DALI-2 DT6/DT8
DC Voltage Range:	120-250Vdc
AC Voltage Range:	100-240Vac
Input Voltage:	115Vac/230Vac
Power Factor:	PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
Efficiency:	87%
Fluctuation Level:	No visible flicker/High frequency exemption level
Output Voltage:	9-42Vdc
Output Current:	200-800mA
Output Power:	1.8W-30W
Dimming Range:	0~100%, down to 0.01%
Certification:	CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,FCC,PSE,EL,ROHS
Warranty:	5 years（Rubycon capacitor）

Download Manual

SE-40-300-1050-W2D

Rubycon capacitor
Dimming Interface:	DALI-2 DT6/DT8
DC Voltage Range:	120-250Vdc
AC Voltage Range:	100-240Vac
Input Voltage:	115Vac/230Vac
Power Factor:	PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
Efficiency:	88%
Fluctuation Level:	No visible flicker/High frequency exemption level
Output Voltage:	9-42Vdc
Output Current:	300-1050mA
Output Power:	2.7W-40W
Dimming Range:	0~100%, down to 0.01%
Certification:	CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,FCC,PSE,EL,ROHS
Warranty:	5 years（Rubycon capacitor）

Download Manual
