The LTECH Triac dimmer series is fully compatible with Triac dimming systems from all brands.
| Wireless Protocol: | Matter over Thread, BLE(Network Configuration & Debugging), NFC(Triac/ELV Parameter Setting) |
| Control Type: | DIM |
| Rated Parameters: | 100-240Vac, 50/60Hz |
| Output Signal: | Triac/ELV |
| Output power: | Incandescent or high-pressure halogen lamps:Max.350W@220Vac, Max.180W@110Vad Dimmable LEDs:Max.180W@220Vac，Max.100W@110Vac |
| Load surge current: | Max.70A |
| Output current: | Max.1.6A |
| Compatible Driver: | Triac/ELV |
| Compatible APP: | NFC Lighting, Apple Home, Smarthings, Google Home, Amazon, Aqara, Tuya |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L86×W86×H52(mm) |
| Package Size: | L102×W102×H73(mm) |
| Weight(G.W.): | 130g |
| Output Signal: | Triac |
| Rated Parameters: | 100-240V~，50/60Hz |
| Control Type: | DIM |
| Wireless Protocol: | Bluetooth 5.0 SIG Mesh |
| Compatible remote: | B1、B2、B8、RC4-BLE |
| Compatible Driver: | Triac driver |
| Compatible APP: | L-Home、 NFC Lighting |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L86xW86xH52(mm) |
| Package Size: | L102xW102xH73(mm) |
| Weight(G.W.): | 130g |
| Wireless Protocol: | Bluetooth 5.0 SIG Mesh |
| Input Voltage: | 100-240V~ |
| Output Signal: | ELV |
| Operating Current: | Max.1.5A |
| Output Power: | ≤180VA/CH(Capacitive load),≤220W/CH(Resistive lode) |
| Inrush Current in Loads: | Max.45A |
| Working Temp.: | -20°C~55°C |
| Dimensions: | L52×W59×H20(mm) |
| Package Size: | L86×W86×H25(mm) |
| Weight(G. W.): | 40g |
| Control Type: | Dimming |
| Dimming Mode: | Leading edge (Triac), Trailing edge (ELV) |
| Input Voltage: | 100-240V~, 50/60Hz |
| Output Power: | Max. 350W (Resistive load).Triac: Max.200W, ELV: Max.300W (Inductive load) |
| Output Current: | Max. 1.5A |
| Anti Surge: | L-N 0.5KV |
| Working Temp.: | -10°C~50°C |
| Dimensions: | L86×W86×H50mm |
| Package Size: | L106×W106×H60mm |
| Weight(G.W.): | 180g |
| Control Type: | Dimming |
| Dimming Mode: | Leading edge (Triac) |
| Input Voltage: | 220-240V~, 50/60Hz |
| Inductive load: | LED Max. 300W |
| Resistor load: | Incandescent lamp Max. 500W |
| Working Temp.: | -10°C~55°C |
| Dimensions: | L86×W86×H50mm |
| Package Size: | L106×W106×H60mm |
| Weight(G.W.): | 180g |
| Dimming Interface: | Triac/ELV |
| Input Voltage: | 100-240Vac |
| Input Current: | ≤2.5A/230Vac |
| Output Signal: | Triac/ELV |
| Output Voltage Range: | 100-240Vac |
| Output Current: | Max. 2.5A |
| Output Power: | Max. 550W |
| Overload Power Limitation: | ≥102% |
| Warranty: | 5 years |
| Dimensions: | L175×W44×H30(mm) |
| Control Mode: | RF wireless control and touch panel control |
| Input Voltage: | 100-240Vac |
| Load inrush current: | Max. 60A |
| Wireless Protocol: | RF 2.4GHz |
| Working Temp.: | -20℃~55℃ |
| Dimensions: | L86×W86×H36(mm) |
| Package Size: | L113×W112×H50(mm) |
| Weight(G.W.): | 225g |
| Input Voltage: | 100~240Vac |
| Wireless Signal: | RF 2.4GHz |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | L55×W55×H21(mm) |
| Package Size: | L65×W65×H26(mm) |
| Weight(G.W.): | 70g |
