0-10V, 1-10V, 10V PWM dimming buttons and dimming modules;
Dimming range: 0~100%, with LED dimming starting from 0.1%, suitable for indoor LED lighting applications.
| Peak current: | 70mA@16V |
| Static current: | 5mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | DALI-2 |
| Output signal: | 0/1-10V×2CH，Max.15mA |
| Load parameters: | Resistive load: 800W@230Vac，400W@110Vac，200W@48Vdc Capacitive load: 300W@230Vac，150W@110Vac，100W@48Vdc |
| Switch maximum voltage: | Max.250Vac，Max.48Vdc |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Peak current: | 70mA@16V |
| Static current: | 5mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | DALI-2 |
| Output signal: | 0/1-10V×2CH，Max.15mA |
| Load parameters: | Resistive load: 800W@230Vac，400W@110Vac，200W@48Vdc Capacitive load: 300W@230Vac，150W@110Vac，100W@48Vdc |
| Switch maximum voltage: | Max.250Vac，Max.48Vdc |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Model: | CG-DAM-PRO |
| Wireless Protocol Type: | Bluetooth 5.0 SIG Mesh |
| Output Signal: | DMX / DALI / 0-10V |
| Input Voltage: | 100-240Vac |
| DALI Output: | 12Vdc (Max.90mA) |
| Working Temperature: | -20°C~55°C |
| Product Size(L×W×H): | 84×35×23(mm) |
| Package Size(L×W×H): | 100×70×42(mm) |
| Weight(G. W.): | 30g |
| Wireless protocol: | Bluetooth5.0 SIG Mesh |
| Power voltage: | 120-277Vac,50/60Hz |
| Load power: | 400VA(Capacitive load),800W(Resistive load) |
| Microwave frequency: | 10.525GHz |
| Emission frequency: | 2dB |
| Stand-by power consumption: | ≤1W |
| Ceiling height: | ≤3.3m |
| Detection range: | ≤6m |
| IP rating: | IP20 |
| Dimensions: | 83*83*72mm(LxWxH) |
| Dimming interface: | DMX/RDM,DALI,Push Dim |
| Output signal: | 0-10V×4CH |
| Output signal logic: | High potential |
| Input voltage: | 100-240Vac/277Vac (277 Vac for North America only) |
| Dimming range: | 0～100% |
| Dimensions: | 175×44×30mm(L×W×H) |
| Pacakge size: | 178×48×33mm(L×W×H) |
| Weight (G.W): | 110g±10g |
