The DALI bus protocol was traditionally used with intelligent lighting controllers and dimmable electronic ballasts for adjusting fluorescent lighting scenes. LTECH's DALI dimming series products comply with IEC 62386/IEC 60929 standards and can be connected to any DALI-compliant device on a single bus for control. This enables the integration of LED lighting products with traditional lighting within a unified lighting system, greatly enhancing user convenience.
| Input signal: | DALI-2 |
| Input Voltage: | 12-48V⎓ |
| Input current: | Max. 20.5A |
| Output Voltage: | 4x(12-48)V⎓ |
| Output Current: | 2x(4CHx2.5A) Max.20A |
| Output Power: | 4CHx(0-60...240)W Max. 960W |
| Working Temp. | -20°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight (G.W) | 670g |
| Waterproof rating: | IP67 |
| Protect: | Short-circuit, over-temperature and over-current protection with automatid reset capability |
| Input signal | DALI |
| Input voltage | 12-48V |
| Output Voltage | 12-48V |
| Output Current | 15A ×1CH |
| Output Power | 0-180...720W（MAX.720W） |
| Dimming Range | 0~100%, LED start at 0.1% possible |
| Dimension | L175×W44×H30(mm) |
| Package Size | L178×W48×H33(mm) |
| Input signal | DALI digital dimming signal |
| Input voltage | DC12V～DC24V |
| Output | 12A ×1CH + 0-10V ×1CH |
| Max output power | 0-144W...288W |
| Dimming Range | 0~100%, LED start at 0.1% possible |
| working temperature | -30℃～55℃ |
| Dimension | L112×W35×H67(mm) |
| Package Size | L114×W37×H70(mm) |
| Weight (G.W) | 120g |
| Input signal | DALI digital dimming signal |
| Input voltage | DC12V～DC24V |
| Output | 12A ×1CH + 0-10V ×1CH |
| Max output power | 144W(12V) 288W(24V) |
| Dimming Range | 0.1～100% |
| working temperature | -30℃～55℃ |
| Dimension | L175×W44×H30(mm) |
| Package Size | L178×W48×H33(mm) |
| Input signal | DALI (IEC62386) |
| Input voltage | DC12V～DC24V |
| Output | 12A ×1CH + 0-10V ×1CH |
| Max output power | 0-144W...288W |
| Dimming Range | 0.1～100% |
| working temperature | -30℃～55℃ |
| Dimension | L175×W44×H30(mm) |
| Package Size | L178×W48×H33(mm) |
| Weight (G.W) | 135g |
| Input signal | DALI, Push Dim |
| Input voltage | 12V～24VDC |
| Output | 5A ×4CH Max 20A |
| Max output power | (0~60W...120W)×4CH Max. 480W |
| Dimming Range | 0～100% |
| working temperature | -30℃～55℃ |
| Dimension | L175×W44×H30(mm) |
| Package Size | L178×W48×H33mm |
| Weight (G.W) | 135g |
