Features DMX, DALI, and 0-10V protocol compatibility with 4 channels and NFC proximity programming. IP67 waterproof rating for outdoor and humid environments. 0-100% dimming depth with PWM digital dimming preserves LED color rendering index. Flicker-free operation throughout, meeting IEEE 1789 high-frequency exemption standards.
| Input signal: | DALI-2 |
| Input Voltage: | 12-48V⎓ |
| Input current: | Max. 20.5A |
| Output Voltage: | 4x(12-48)V⎓ |
| Output Current: | 2x(4CHx2.5A) Max.20A |
| Output Power: | 4CHx(0-60...240)W Max. 960W |
| Working Temp. | -20°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight (G.W) | 670g |
| Waterproof rating: | IP67 |
| Protect: | Short-circuit, over-temperature and over-current protection with automatid reset capability |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12-48V⎓ |
| Input current: | Max. 20.5A |
| Output Voltage: | 4x(12-48)V⎓ |
| Output Current: | 2x(4CHx2.5A) Max.20A |
| Output Power: | 4CHx(0-60...240)W Max. 960W |
| Working Temp. | -20°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight (G.W) | 670g |
| Waterproof rating: | IP67 |
| Protect: | Short-circuit, over-temperature and over-current protection with automatid reset capability |
| Input signal: | 0/1-10V |
| Input Voltage: | 12-48V⎓ |
| Input current: | Max. 20.5A |
| Output Voltage: | 4x(12-48)V⎓ |
| Output Current: | 2x(4CHx2.5A) Max.20A |
| Output Power: | 4CHx(0-60...240)W Max. 960W |
| Working Temp. | -20°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight (G.W) | 670g |
| Waterproof rating: | IP67 |
| Protect: | Short-circuit, over-temperature and over-current protection with automatid reset capability |
| Input signal | DMX512/RDM |
| Input Voltage | 12-24V |
| Output Current | Max. 5A/CH Max. 20A(4CH) |
| Output Power | (0-60...120)W/CH Max. 480W(4CH) |
| Dimming Range | 0-100% |
| Working Temp. | -20°C~50°C |
| Dimensions(L×W×H) | L164×W70×H36mm |
| Package Size(L×W×H) | L193×W127×H41mm |
| Weight (G.W) | 690g |
| Protection | Short circuit, over temperature, over current protection, auto recovery. |
