Product features:
1. T-PWM® super-deep dimming technology, dimming starting from 0.1%. 2. Flicker-free dimming across the entire range, meeting the High-Frequency Exemption Level. 3. NFC Programmable Technology: Allows configuration of parameters (e.g., output current, dimming curve) and driver data exchange via a mobile app. 4. EU ErP Compliance: No-load and networked standby power consumption is <0.5W· 0V No-Load Output prevents damage to LEDs caused by poor contact. 5. novative Thermal Management, intelligently extending driver service life. 6. Protection against Over-Temperature, Over-Load, and Short-Circuit, with Auto-Recovery.
CC Dimmable Driver
    • SE-12-100-500-W1M
      SE-12-100-500-W1M
      Rubycon capacitor
      Dimming Interface: DMX512/RDM
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 84%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-500mA
      Output Power: 0.9W~12.15W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,CUL,UL,ERP,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-12-100-500-W2M
      SE-12-100-500-W2M
      Rubycon capacitor
      Dimming Interface: DMX512/RDM
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 84%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-500mA
      Output Power: 0.9W~12.15W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,CUL,UL,ERP,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-12-100-500-W1A
      SE-12-100-500-W1A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 84%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-500mA
      Output Power: 0.9W~12.15W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,FCC,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-12-100-500-W2A
      SE-12-100-500-W2A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 84%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-500mA
      Output Power: 0.9W~12.15W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-40-300-1050-W2M
      SE-40-300-1050-W2M
      Rubycon capacitor
      Dimming Interface: DMX512/RDM
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.9/230Vac, at full load
      Efficiency: 88%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 300-1050mA
      Output Power: 2.7W-40W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-20-100-700-W1A
      SE-20-100-700-W1A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 86%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-700mA
      Output Power: 0.9W~20.4W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,FCC,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-20-100-700-W2A
      SE-20-100-700-W2A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 86%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-700mA
      Output Power: 0.9W~20.4W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,FCC,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-20-100-700-W1M
      SE-20-100-700-W1M
      Rubycon capacitor
      Dimming Interface: DMX512/RDM
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 86%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-700mA
      Output Power: 0.9W~20.4W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-20-100-700-W2M
      SE-20-100-700-W2M
      Rubycon capacitor
      Dimming Interface: DMX512/RDM
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 86%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-700mA
      Output Power: 0.9W~20.4W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-30-200-800-W1A
      SE-30-200-800-W1A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
      Efficiency: 87%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 200-800mA
      Output Power: 1.8W-30W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,ROHS
      Warranty: 5 years(Rubycon capacitor)
      [field:title/]
      Download Manual


    • SE-40-300-1050-W1A
      SE-40-300-1050-W1A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
      Efficiency: 88%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 300-1050mA
      Output Power: 2.7W-40W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,ROHS
      Warranty: 5 years(Rubycon capacitor)
      [field:title/]
      Download Manual


    • SE-30-200-800-W2A
      SE-30-200-800-W2A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
      Efficiency: 87%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 200-800mA
      Output Power: 1.8W-30W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,ROHS
      Warranty: 5 years(Rubycon capacitor)
      [field:title/]
      Download Manual


    • SE-40-300-1050-W2A
      SE-40-300-1050-W2A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
      Efficiency: 88%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 300-1050mA
      Output Power: 2.7W-40W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,ROHS
      Warranty: 5 years(Rubycon capacitor)
      [field:title/]
      Download Manual


    • SE-12-100-500-W1D
      SE-12-100-500-W1D
      Rubycon capacitor
      Dimming Interface: DALI DT6
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 84%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-500mA
      Output Power: 0.9W~12.15W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,FCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-12-100-500-W2D
      SE-12-100-500-W2D
      Rubycon capacitor
      Dimming Interface: DALI-2 DT6/DT8
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 84%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-500mA
      Output Power: 0.9W~12.15W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,FCC,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-20-100-700-W1D
      SE-20-100-700-W1D
      Rubycon capacitor
      Dimming Interface: DALI DT6
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 86%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-700mA
      Output Power: 0.9W~20.4W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,FCC,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-20-100-700-W2D
      SE-20-100-700-W2D
      Rubycon capacitor
      Dimming Interface: DALI-2 DT6/DT8
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 86%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-700mA
      Output Power: 0.9W~20.4W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,FCC,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-30-200-800-W1D
      SE-30-200-800-W1D
      Rubycon capacitor
      Dimming Interface: DALI DT6
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.9/230Vac, at full load
      Efficiency: 87%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 200-800mA
      Output Power: 1.8W-30W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-40-300-1050-W1D
      SE-40-300-1050-W1D
      Rubycon capacitor
      Dimming Interface: DALI DT6
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.9/230Vac, at full load
      Efficiency: 88%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 300-1050mA
      Output Power: 2.7W-40W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-30-200-800-W2D
      SE-30-200-800-W2D
      Rubycon capacitor
      Dimming Interface: DALI DT6/DT8
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.9/230Vac, at full load
      Efficiency: 87%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 200-800mA
      Output Power: 1.8W-30W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-40-300-1050-W2D
      SE-40-300-1050-W2D
      Rubycon capacitor
      Dimming Interface: DALI DT6/DT8
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.9/230Vac, at full load
      Efficiency: 88%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 300-1050mA
      Output Power: 2.7W-40W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual




About Us

Product Center

Follow us

Contact Us

  • +86 756 620 8255
  • +86 756 620 8836
  • (Monday to Friday 8:30-18:00)
Legal Disclaimer | Privacy protection | Contact us
COPYRIGHT © 2003-2025 LTECH. ALL RIGHT RESERVED.
    粤ICP备10035980号    粤公网安备 44049002000101号
