One remote controls countless devices within a 30-meter range with unlimited control capacity. Single-zone/multi-zone remote operation adapts to your needs, enabling simultaneous control of multiple devices in Zone 1. Utilizing 2.4GHz wireless technology and RF radio frequency remote control, it delivers exceptional penetration and stable operation.
Comes with a wall-mountable base; powered by a CR2032 button battery for ultra-low power consumption.
| Dimming mode: | RGBCW |
| Wireless Protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery CR2032×1) |
| Standby current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -30℃～55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | RGBW |
| Wireless Protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery CR2032×1) |
| Standby current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -30℃～55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | RGB |
| Wireless Protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery CR2032×1) |
| Standby current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -30℃～55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | CT |
| Wireless Protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery CR2032×1) |
| Standby current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -30℃～55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | DIM |
| Wireless Protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery CR2032×1) |
| Standby current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -30℃～55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White |
| Wireless Protocol: | RF 2.4GHz |
| Working Voltage: | 3Vdc (Button cell CR2032×1) |
| Standby Current: | <1uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -10°C~50°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming Mode: | DIM |
| Wireless Protocol: | RF 2.4GHz |
| Working Voltage: | 3Vdc (Button cell CR2032×1) |
| Standby Current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -10°C~50°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming Mode: | CT |
| Wireless Protocol: | RF 2.4GHz |
| Working Voltage: | 3Vdc (Button cell CR2032×1) |
| Standby Current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -10°C~50°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | RGBW |
| Wireless Protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -10°C~50°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming Mode: | RGBCW |
| Wireless Protocol: | RF 2.4GHz |
| Working Voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -10°C~50°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming Mode: | DIM |
| Wireless Protocol: | RF 2.4GHz |
| Working Voltage: | 3Vdc (Button cell CR2032×1) |
| Standby Current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -10°C~50°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming Mode: | CT |
| Wireless Protocol: | RF 2.4GHz |
| Working Voltage: | 3Vdc (Button cell CR2032×1) |
| Standby Current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -10°C~50°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming Mode: | RGBW |
| Wireless Protocol: | RF 2.4GHz |
| Working Voltage: | 3Vdc (Button cell CR2032×1) |
| Standby Current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -10°C~50°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming Mode: | RGBCW |
| Wireless Protocol: | RF 2.4GHz |
| Working Voltage: | 3Vdc (Button cell CR2032×1) |
| Standby Current: | <2uA |
| Control Distance: | 30 meters (under ideal conditions) |
| Working Temp.: | -10°C~50°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 11A 11A@12V 11A@24V 11A@36V 11A@48V |
| Load Power: | 132W@12V 240W@24V 288W@36V 384W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 12A 6A/CH@12V 5A/CH@24V 4A/CH@36V 4A/CH@48V |
| Load Power: | 144W@12V 240W@24V 288W@36V 384W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 15A 5A/CH@12V 5A/CH@24V 4A/CH@36V 3A/CH@48V |
| Load Power: | 180W@12V 360W@24V 432W@36V 432W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 15A 3.75A/CH@12V 3A/CH@24V 2.5A/CH@36V 2.5A/CH@48V |
| Load Power: | 180W@12V 288W@24V 360W@36V 480W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 15A 3A/CH@12V 3A/CH@24V 2.5A/CH@36V 2.5A/CH@48V |
| Load Power: | 180W@12V 360W@24V 450W@36V 600W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
